SKU: BSEA-2304B

Blue Sea Systems 2304 Marine Mini Common Bus Bar 5 X #8-32 Screw 5 Gang 100 Amp

$21.95 USD
$21.95 USD
Sale Sold out

Product Description

  • Specifications:
  • Maximum Voltage 300V AC
  • 48V DC
  • Number of Screw Terminals 5
  • Number of Terminal Studs 2
  • Terminal Type #10-32 Stud
  • #8-32 Screw
  • Continuous Rating The maximum current a switch is designed to conduct for an indefinite period.  100A
  • Base Material UL 94-V0 Rated, Glass Reinforced Thermoplastics
  • Bus Material Tin-Plated Copper CDA 110/ UNS11000
  • Screw Terminal Torque 15 in-lb (1.69 Nm)
  • Stud Torque 18 in-lb (2.03 Nm)
  • Weight 0.16lb (0.07 kg)
